Getrag 7DCL750 Engine Hoist Eye Bolt Set

The Getrag 7DCL750 Engine Hoist Eye Bolt Set is a purpose built lifting tool for the 7DCL750 gearbox. It contains three eye bolts that thread directly into the factory threaded holes on the top of the transmission case. Because the 7DCL750 is a heavy and asymmetric unit, lifting it with a single point or an improvised strap setup causes the gearbox to rotate. That rotation puts stress on the output shafts, the bell housing, and any components still connected during removal. So having three dedicated lifting points is not a convenience. It is the correct way to handle this gearbox.

Each eye bolt in this set threads into one of the existing factory holes on the top of the 7DCL750 case. The threads are already there from the factory. Because of that, no drilling, tapping, or modification to the transmission is required. Once the three bolts are installed, you attach hoist chains or hooks to each eye. That creates a three point lifting configuration that distributes the weight of the gearbox evenly across all three points. The result is a balanced lift that keeps the transmission level and prevents rotation throughout the entire removal or installation process.

Each eye bolt in this set features a 0.5 inch diameter hook opening. This opening accepts standard engine hoist hooks and chain links used in professional transmission removal setups. Before starting the lift, confirm that your hoist hooks fit the 0.5 inch opening. Using an oversized hook that does not seat fully in the eye is a safety risk. This set works with standard professional lifting equipment and does not support use in improvised rigging setups.

The 7DCL750 is not a symmetrical gearbox. The CCP, SAP, and differential assembly create an uneven weight distribution across the case. When a single lift point is used, the heavier end drops and the gearbox rotates. That rotation can damage the output shaft seals, stress the bell housing alignment, and make it nearly impossible to guide the unit into position during installation. With three lift points, the weight distribution is controlled. The technician can adjust the chain lengths to level the gearbox before the lift begins. That makes the removal and reinstallation process significantly safer and more precise.

Automakers equip a wide range of high performance models with the Getrag 7DCL750 transmission. This includes the Ferrari 458 Italia, 458 Spider, 458 Speciale, 488 GTB, 488 Spider, Ferrari FF, GTC4 Lusso, Mercedes AMG GT, and Ford GT. By installing the 7DCL750 in these vehicles, manufacturers take advantage of its fast shift times, durability, and ability to handle the power and torque produced by modern supercar engines. This eye bolt set fits all 7DCL750 applications. Contact us before ordering if you need to confirm fitment for a specific variant.
